Feature Wiki

Information about planned and released features

Tabs

Introduce ::before selector for lists

Page Overview

1 Initial Problem
2 Conceptual Summary
3 3 User Interface Modifications
- 3.1 List of Affected Views
- 3.2 User Interface Details
- 3.3 New User Interface Concepts
- 3.4 Accessibility Implications
4 Technical Information
5 Privacy
6 Security
7 Contact
8 Funding
9 Discussion
10 Implementation

1 Initial Problem

The possibilities to design lists using Content Style in ILIAS are limited. New styles can be added, but the possibilities to customize the list are limited to the background color. Numbering and content cannot be styled separately.

2 Conceptual Summary

For this purpose, lists are to be revised and the numbering/bullets are no longer to be displayed using ::marker, but ::before. Using ::before instead of ::marker allows us full access to CSS properties for custom styling, as well as permitting animations and transitions - for which support is limited for ::marker.

In addition to the revision, the ::before-tab is to be displayed in the editing view of Lists in the Content Style.

Similar to the ::hover-tab for blocks, attributes of the ::before elements, i.e. the numbering or the bullets, can be defined in this tab.

li::before {
counter-increment: list-item;
content: counter(list-item);
}

New custom list item Classes with ::before properties as next tab

Unless the user has not selected the "List" element, the styles are not displayed.

Text Editor slate the "Lists" element was NOT selected

Once user has selected the "List" element, additional List Styles section is faded in.

Drop Downs to select a Style for Lists and a Style for List Items is presented while the text area is set to List element.

3 3 User Interface Modifications

3.1 List of Affected Views

Administration > Layout and Navigation > Layout and Styles > Content Styles > Specific Style > Style Classes > ListItems

3.2 User Interface Details

see above

3.3 New User Interface Concepts

none

3.4 Accessibility Implications

The elements are already used in the same slate. The accessibility of the drop down is ok.

4 Technical Information

No technical issues.

5 Privacy

Current state of the COPage component: https://github.com/ILIAS-eLearning/ILIAS/blob/trunk/Services/COPage/PRIVACY.md

This feature request does not include and privacy related changes.

6 Security

No forseen security implications.

7 Contact

Author of the Request: Zenzen, Enrico [ezenzen], Tödt, Alexandra [atoedt]
Maintainer: Killing, Alexander [alex]
Implementation of the feature is done by: {The maintainer must add the name of the implementing developer.}

8 Funding

If you are interest in funding this feature, please add your name and institution to this list.

9 Discussion

Killing, Alexander [alex], 7 June 2023: I fear this is not that easy. First of all, it is possible to select the list(!) style for advanced lists on the setting screen. The simple lists do not offer this, this is true. If I understand the requirement correctly, you want to introduce the ::before selector for list items, not for lists. Currently it is not possible to add new list item classes, only new list classes. So we need a) custom list item classes b) the ::before properties for list items and c) two dropdowns in the slate for selecting list and list item style. I would suggest to keep the list buttons as they currently are and to add two list style select dropdowns (if mutliple styles are available) separately to the slate.

Tödt, Alexandra [atoedt] 2023 June, 20th: I made changes to the request to reflect the above comment of Alexander.

JourFixe, ILIAS [jourfixe], 24 JUL 2023: We highly appreciate this suggestion and schedule the feature for ILIAS 9.

10 Implementation

{ The maintainer has to give a description of the final implementation and add screenshots if possible. }

Screenshots
